Windstrong Series B Industrial / Farm

Store/Doors

AU$0.00

Select Door Size

Please choose

Enter Curtain Width - Opening Size plus 100mm

Enter your text

Enter Colorbond colour or Zincalume

Enter your text

Identify your location for distribution allowance

Please choose

Remote Motor - if desired

Please choose

Transit Protective Packaging - Recommended

Please choose

Planetary Gearing - for large doors marked <p> if not using a motor

Planetary Gearing - required for large doors <p> without motors (+AU$212.00)

Quantity:

Save this product for later

Windstrong Series B Industrial / Farm

Store/Doors

Product Details

Even Industrial Roller Doors in Cyclone and High Wind areas need to have special design considerations. They need to consider the building code AS/NZS 4505:2012.

Whilst the codes refer to doors under 3m high the building specifiers and certifiers are likely to reference the new code and when it comes to the NT & FNQ you will certainly need Windstrong Doors. To this end, Taurean Door Systems whose quality design and value, made possible by decades of design knowledge can provide their Series B “WINDSTRONG DOOR” to meet your Industrial building code obligations of having a Wind Locked Door.

How do Wind Locks work? The WINDSTRONG™ Windlock Roller Door has a riveted wind-clip at every second flat on the roller door curtain. These are at a spacing of 7 clips per metre on each side of the door. When the door is in the closed position every wind-clip is supported by two steel brackets that are attached to the track. These brackets in turn are fixed to the door Jamb. Have a look at this detailed technical brochure

HOW TO ORDER WINDSTRONG™ ROLLER DOORS SERIES B INDUSTRIAL

Go here if you’re looking for “Series A & AA” Domestic Size Windstrong Doors.
Confirm height & width of your buildings opening.
Select the correct door size below based on your required width and height.
Select door colour you want.
Enter specific door curtain width required in the box provided. Opening width + 100mm
Select your location to allow for transport cost from Factory to Depot.
Add a powerful Grifco LR-Drive Remote Motor if desired for Windstrong doors upto 22 m2.
Doors Marked <P> require Planetary Gearing if not used with a Motor. Add Planetary gearing if required.
Select protective door wrapping (recommended)
Delivery to site is $182.50. If you like you can choose to pick up from a Stramit Depot for free during checkout
We will contact you to confirm door measurements before manufacturing.

Other Roller Doors Available

Domestic Roller doors – Series A & AA
Industrial – Bigger Roller doors – Series B
Windstrong Series A & AA Roller doors – Windlocked Series A & AA
Installation instructions – Domestic – Industrial – Windstrong

Find out how to install this product

Windstrong doors are classified for use both as a Domestic door in Class 1 and 10 buildings to 20,000 cycles, and as a General Purpose – Medium Cycle door in Class 1 to 10 buildings to 20,000 cycles.

Each WINDSTRONG™ door has a stylish curtain made from the highest quality steel and is available in a wide range of popular colours.

Doors are available in very wide range of opening sizes up to 3100 high is series A and 5100mm high in Series B and up to 5400mm wide series AA…to suit single and double car garages for your home and larger sheds and buildings.

Commando Collection Features and Benefits

Rounded formed panel – Stylish appeal
Colours – COLORBOND® steel and ZINCALUME® steel
Glass-filled nylon drum wheels – Quiet operation
Nylon braid edging – Smooth operation of door in tracks
Nylon bottom rail plug – Smooth operation of door in tracks
Flexible sealing strip – helps prevent dust and leaves entering the garage
Galvanised tracks – Galvanising ensures long life by minimising corrosion
Galvanised brackets – Galvanising helps minimise corrosion ensuring long life
Track stops – Assists in keeping the door in the tracks
Reverse roll – Ecternal installation when no inside headroom available
Spring system – 25,000+ cycles
Sizes – Up to 5100mm high and 5100mm wide
12 month warranty

FREQUENTLY ASKED QUESTIONS

Which personal access door should I get?

Two brands are available, Larnec & Taurean. Both Australian Made.

Manufacture time varies from 10 working days to 25 working days depending on the model of door. The Standard shed doors – Larnec Sentry 650, tend to be at the 10-day end of the supply range. The Taurean range of doors has a 4-week lead time.

The heavy-duty, more customised Larnec models take longer so please ask us if your timeline is critical.

If your site or home is deemed remote by the freight forwarders it may be necessary to collect from a regional centre near you.

Where are Taurean Roller Doors made

Australian made in Victoria and delivered through the Stramit Industries network.

Taurean Roller door deliverys

Delivery – For a modest charge you can have site delivery to most destinations that are near the main national highway network or you can collect by arrangement from a Stramit depot for only a small charge.

Which roller door should I get?

Roller Doors – ordering width questions.

For Series A domestic door openings upto 3m wide you should add 25mm each side for the tracks, Eg. if your framed opening is 2.8m you should order a door curtain 2850mm wide. If your opening is 3m you should order a door curtain 3050 wide.

For AA extra wide domestic roller door openings over 3m wide upto 5.1m wide you should order with 50mm each side for tracks. Eg 5m wide opening order a 5100mm wide curtain, for 4.2m opening order a 4300mm wide curtain.

For any series B light industrial doors there large tracks needing 50mm of curtain each side. So order 100mm wider than the opening. Eg 4m wide opening, order a 4100mm wide curtain . 5m opening, order 5100mm wide curtain.

You should order planetary gearing with larger doors that are marked with <p> on our order forms

Do Roller Doors come with tracks and mounting brackets?

Yes they do as standard, also, Domestic doors have a lock set.

Commercial doors have chain operation and no lock set.

Over about 3.5m you should consider adding Planetary Gearing. We note these size doors on our website.

How wide should I order my door?
